Product specification Bag material 600D Bag color Camouflage color or OEM color Open size( MM)1820*620Folding size (MM)460*620Foldinjg thickness (MM)55Net weight (KG)5.70 KGSolar panel Solar Cell Monocrystalline Efficiency rate 21.5%Maximum power(W) 160Power Tolerance ±5%Voltage at max ......
| Product specification | |
| Bag material | 600D |
| Bag color | Camouflage color or OEM color |
| Open size( MM) | 1820*620 |
| Folding size (MM) | 460*620 |
| Foldinjg thickness (MM) | 55 |
| Net weight (KG) | 5.70 KG |
| Solar panel | |
| Solar Cell | Monocrystalline |
| Efficiency rate | 21.5% |
| Maximum power(W) | 160 |
| Power Tolerance | ±5% |
| Voltage at max power(Vmp) (V) | 19.8V |
| Current at max power(Imp) (A) | 8.08A |
| Open circuit voltage(Voc) (V) | 23.36V |
| Short circuit current(Isc) (A) | 8.89A |
| Operating Temperature (ºC) | -20 to 50ºC |
| Maximum System Voltage (V) | 100V |
| Maximum Series Fuse Rating(A) | 10A |
| Standard Test Condtion | Irrandiance 1000W/M2 Module temperature 25ºC,AM=1.5 |
| Warranty | Power is not less than 90% in 5 years |
| Resistances | 227g stell ball fall down from 1m height and 60m/s wind |
| Noct | 46ºC ± 2ºC |
| Current temperature coefficient | 0.05%/°C |
| Voltage temperature coefficient | - 0.35%/°C |
| Power temperature coefficient | - 0.45%/°C |
Main Features:
(4) Rainproof;
(2) Assured quality, with full power, long durability;
Warranty Policy:
