Solar Energy System Storage Inverter 500W for Motor Factory USA Model

Product Description

Solar Energy System Storage Inverter 500W For Motor Factory USA Model

Products Specification:

	Model	SPB-500
Inverter AC output	Ouput Rated Power	500W
	Ouput Peak Power	1000W
	Waveform	Pure sine wave
	Frequency	50HZ±3 or 60HZ±3
	Ouput Voltage	100V-120VAC±5%	220V-240VAC±5%
	Output Outlet	Universal(Japan,USA,UK,Europe, Austrial optional)
	Soft start	yes
	THD	THD<3%
	Protect	Over-voltage, low voltage, overload, over-temperature, short-circuit
DC Output	USB -A	5V 2.4A Fast charging *1
	USB- B	QC3.0 Super-fast charging *1
	Type-c	PD Standard, input/output support 60W:5V3A,9V3A,12V3A,15V3A,20V3A
	DC Socket(6530)	12VDC*2 /10A output
	Cigarette output	DC12V/10A
DC Input	Solar Charger(6530)	PWM charger max 15A
	Grid Charger (6530)	Power Adapter 6A
AC Input	Grid Input	With UPS function
LED light	LED Lighting 8W
Switch	DC12V output switch,USB switch,Inverter switch,LED light switch(press 3S to on/off)
Display	Display type	LED Intelligent display
	Display content	Battery capacity, battery voltage, output voltage, output waveform, frequency, AC load percent, USB status, DC outpu status, LED light status, grid charger working status, solar charging status, blue tooth status
Lithium Battery	Battery type	18650/2.6AH LiO2 battery cell
	Capacity	538WH
	Battery Voltage Range	12.6V-16.8V
	Min Charging Current	5A
	Max continous Charging Current	45A
	Max continous Discharge Current	60A
	Max Peak Discharge Current	120A(60S)
Cooling Way	Intelligent Fan
Working Temperature	(0ºC+60ºC)
Storage Temperature	(-20ºC - 70ºC)
Humidity	Max 90%,Non-condensing
Warantee	2 Years
Size	220185144mm
